sales@bitsfrombytes.com +44 (0)1275 873792 Document No D100246

BFB 3000 Operations manual

step

• Loosen the hex nuts using a 2.5mm allen key to loosen the hex bolts at the bottom of the wiper blade.

• Move the extruder to a position behind the nozzle wiper blade

Unpacking and assembling BFB 3000

Loose hex

nuts and

bolts

Move Extruders

behind the nozzle

wiper blade
