BFB 3000 Operations manual

Unpacking and assembling BFB 3000

step – Cont

• Adjust the wiper blade until it looks like it will gently wipe the end of the nozzle.

• Move the extruder past the blade to check the extruder gently makes contact with the wiper blade to remove any

filament residues. Please note the height should mean the extruder nozzle only just makes contact with the

wiper blade

• Make sure the blade is set square.

• Once the height has been set, retighten the hex bolts.

Right height

Too high

Too low
