sales@bitsfrombytes.com +44 (0)1275 873792 Document No D100246

BFB 3000 Operations manual

Control interface – manual move

+ Y:

Move the Y axis in a

forward direction

- X:

Move the X axis to

the left

+ X:

Move the X to the

right

- Y:

Move the Y axis in a

backward direction

+ Z:

Move the Z axis in

an upward direction

- Z:

Move the Z axis in a

downward direction

Esc:

Return to main

Manual move allows back to front and side to side movement of the extruder

heads and up and down movement of the bed

Typically used when levelling the bed

To navigate to “MANUAL

MOVE”

Use the Y – or Y + buttons in main

menu and press X+/Enter when

“MANUAL MOVE” is selected.
