sales@bitsfrombytes.com +44 (0)1275 873792 Document No D100246

BFB 3000 Operations manual

step

• Once the base panel is securely fitted to the main unit, put the BFB 3000 onto its feet.

• Fit the electronics unit into the slots on the front panel of the machine as shown.

• Fit the nozzle wiper box using the three machined aluminium pegs, making sure the metal blade is toward the

front of the machine.

Fit nozzle wiper

onto aluminium

pegs.

Blade to the front

Unpacking and assembling BFB 3000

Fit electronics to

the front panel.
