BFB 3000 Operations manual

step

• Place the electronics outside the frame through the bottom of the case and slot the conduit into the cut out as shown.

• Remove all 4 nuts holding the feet on the base and remove the feet from the base panel.

Conduit to sit in

the case cut out

Remove all 4

nuts from the

feet

Unpacking and assembling BFB 3000
